i2R CNC - Performance 16 CNC Machine
Order in the next [totalHours] hours %M minutes to get it between and
Description
Product Description
The PERFORMANCE 16 features a spacious 48" x 48" cutting area, a 3HP liquid-cooled spindle, and our advanced iCNC 15.6” touchscreen Controller. Built for high-output shops, it delivers industrial-grade performance, precision, and durability for demanding production environments.
Features
- 3HP Liquid-Cooled Spindle
- 48" x 48" Cutting Area
- 15.6" Touchscreen Controller
- Tool Touch-Off Puck
- 1/4" Collet + 1/2" Collet
- Hold Down Clamps - Set of 2
- Performance 16 Stand
- Wrench Set
- iCNC Monitor Arm
- Grease Gun
- Liquid Gooled Module
Specifications
| Specification | Details |
|---|---|
| X-Axis Travel | 48" (1220mm) |
| Y-Axis Travel | 48" (1220mm) |
| Z-Axis Travel | 7.87" (200mm) |
| Spindle Type | 3HP Water Cooled |
| Spindle Configuration | ER20 (1/4" & 1/2") |
| Controller | iCNC (15.6" Touch Screen) |
| Rapid Feed Rate | 300ipm (5m/min) |
| Resolution | ± 0.00393" (0.10mm) |
| Power Requirements | 220V, 50–60Hz, 10A, 1-Phase |
| Machine Base | Welded Steel |
| Working Table | High Rigidity Aluminum Extrusion |
| Gantry Bridge | High Rigidity Aluminum Extrusion |
| Gantry Supports | Aluminum Alloy Gravity Cast |
| Machine Dimensions | 64.7"L × 62.1"W × 59.8"H (1643mm × 1577mm × 1518mm) |
i2R CNC - Performance 16 CNC Machine
$13,999.00
