i2R CNC - Discovery 1 CNC Machine
Order in the next [totalHours] hours %M minutes to get it between and
Description
Product Description
The DISCOVERY 1 delivers a compact solution for makers with limited space, and manufacturing small products or prototypes. With a 12” x 12” workspace, each model is built with premium ball screws, linear guideways, an intuitive eCNC controller with a 7″ touchscreen, and 1HP Air-Cooled Spindle.
Features
- 12" x 12" Workspace
- Tool Touch-Off Puck
- Wrench Set
- 1/8" Collet + 1/4" Collet
- Hold Down Clamps - Set of 2
Specifications
| Specification | Details |
|---|---|
| X-Axis Travel | 12" (305mm) |
| Y-Axis Travel | 12" (305mm) |
| Z-Axis Travel | 5.5" (140mm) |
| Spindle Type | 1HP Air Cooled |
| Spindle Configuration | ER11 (1/8" & 1/4") |
| Controller | eCNC (7" Touch Screen) |
| Rapid Feed Rate | 150ipm (3.81m/min) |
| Resolution | ± 0.00393" (0.10mm) |
| Power Requirements | AC 110V, 50–60Hz, 15A, 1-Phase (Optional 220V, 50–60Hz, 10A, 1-Phase) |
| Machine Base | High Rigidity Aluminum Extrusion |
| Working Table | High Rigidity Aluminum Extrusion |
| Gantry Bridge | High Rigidity Aluminum Extrusion |
| Gantry Supports | Steel Plate |
| Machine Dimensions | 23.76"L × 23.23"W × 28.11"H (603.5mm × 590mm × 714mm) |
i2R CNC - Discovery 1 CNC Machine
$4,999.00
