i2R CNC - Academy 1 CNC Machine
Order in the next [totalHours] hours %M minutes to get it between and
Description
Product Description
The ACADEMY 1 is a compact, fully enclosed desktop CNC machine designed for makerspaces and small workshops. It features a 12” x 12” cutting area, a 1HP spindle, and an integrated dust shoe with external suction connection, delivering clean, quiet performance right from the workbench.
Features
- 12" x 12" Cutting Area
- 1HP Spindle
- Integrated Dust Shoe w/ External Suction Connection
- Tool Touch-OFF Puck
- Wrench Set
- 1/8" Collet + 1/4" Collet
- Hold Down Clamps - Set of 2
Specifications
| Specification | Details |
|---|---|
| X-Axis Travel | 12" (305mm) |
| Y-Axis Travel | 12" (305mm) |
| Z-Axis Travel | 5.5" (140mm) |
| Spindle Type | 1HP Air Cooled |
| Spindle Configuration | ER11 (1/8" & 1/4") |
| Controller | eCNC (7" Touch Screen) |
| Rapid Feed Rate | 150ipm (3.81m/min) |
| Resolution | ± 0.00393" (0.10mm) |
| Power Requirements | AC 110V, 50–60Hz, 15A, 1-Phase (Optional 220V, 50–60Hz, 10A, 1-Phase) |
| Machine Base | High Rigidity Aluminum Extrusion |
| Working Table | High Rigidity Aluminum Extrusion |
| Gantry Bridge | High Rigidity Aluminum Extrusion |
| Gantry Supports | Steel Plate |
| Machine Dimensions | 31.5"L × 29.1"W × 36.8"H (800mm × 740mm × 935mm) |
i2R CNC - Academy 1 CNC Machine
$7,999.00
